ESP32 Web Server Example: Step-by-Step Setup Guide

Oct 15, 2026 · 5 min read · Beginner

What hardware and software do you need?

Before writing a single line of code, get these items ready.

Hardware

• ESP32 development board
• USB cable for programming and power
• A 2.4 GHz Wi-Fi router you can join

Software

• Arduino IDE with the arduino-esp32 board package installed
• ESPAsyncWebServer library
• AsyncTCP library (ESPAsyncWebServer depends on it)

WiFi.h ships with the arduino-esp32 core and needs no separate install. ESPAsyncWebServer and AsyncTCP must be added through the Arduino IDE Library Manager or installed manually.

If you prefer the ESP-IDF toolchain instead of Arduino, Espressif's built-in HTTP server component provides httpd_start(), httpd_stop(), and httpd_register_uri_handler() and requires no extra libraries.

How do you write the ESP32 web server code? (Step-by-step)

The sketch below is built directly from the example code in the sources. Replace your_ssid and your_password with your network credentials before uploading.

#include <WiFi.h>
#include "ESPAsyncWebServer.h"

AsyncWebServer server1(81);

const char* ssid     = "your_ssid";
const char* password = "your_password";

void setup() {
  Serial.begin(115200);

  WiFi.begin(ssid, password);
  while (WiFi.status() != WL_CONNECTED) {
    delay(1000);
    Serial.println("Connecting to WiFi..");
  }
  Serial.println("Connected to the WiFi network");
  Serial.println(WiFi.localIP());

  server1.on("/test_data", HTTP_GET, [](AsyncWebServerRequest *request){
    request->send(200, "text/plain", "Hello from ESP32");
  });

  server1.begin();
}

void loop() {
  // Other application logic can run here
}

What each step does:

1. Include headers. WiFi.h provides WiFi.begin() and WiFi.localIP(). ESPAsyncWebServer.h brings in the server class and the request/response types.
2. Create the server object. AsyncWebServer server1(81) creates a server that listens on port 81. Pass a different number to use a different port.
3. Open Serial. Serial.begin(115200) lets you read status messages and the board's assigned IP address in the Serial Monitor.
4. Connect to Wi-Fi. WiFi.begin(ssid, password) starts the connection attempt. The while loop polls WiFi.status() every second and blocks until WL_CONNECTED is returned — only then does execution continue.
5. Print the IP address. WiFi.localIP() returns the address the router assigned to the ESP32. Write it down — you will type it into a browser.
6. Register a route. server1.on("/test_data", HTTP_GET, handler) maps every GET request arriving at /test_data to a lambda. Inside the lambda, request->send(200, "text/plain", "...") sends an HTTP 200 response with a plain-text body.
7. Start the server. server1.begin() opens the listening socket and the server begins accepting connections.

How do you verify the web server is working?

1. Select your ESP32 board and the correct COM port in Arduino IDE, then click Upload.
2. Open the Serial Monitor (Tools → Serial Monitor) and set the baud rate to 115200.
3. Wait for "Connected to the WiFi network". The very next line will show an IP address such as 192.168.1.42.
4. On a device connected to the same Wi-Fi network, open a browser and navigate to:

   http://192.168.1.42:81/test_data


   Replace the IP with the one printed in your Serial Monitor.
5. The browser should display the text your request->send() call returns. If you see it, the server is working correctly.

If the IP address never appears: re-check your SSID and password, and confirm the router is a 2.4 GHz network.

How do you make the page update automatically?

A plain HTTP response does not refresh on its own. The sources describe two approaches.

Option 1 — HTML meta refresh tag (simplest)

Change the handler to return HTML instead of plain text, and include a <meta http-equiv="refresh"> tag in the <head>. The value in content= is the reload interval in seconds.

server1.on("/test_data", HTTP_GET, [](AsyncWebServerRequest *request){
  String html = "<html><head><meta http-equiv=\"refresh\" content=\"30\"></head><body>"
                + String("your data here") + "</body></html>";
  request->send(200, "text/html", html.c_str());
});

Change 30 to whatever interval you want. The browser handles the reload entirely on the client side — the ESP32 simply sends normal HTML each time a request arrives.

Option 2 — Client-side JavaScript

The sources also mention using JavaScript on the client side as an alternative, for example using fetch() to poll an endpoint and update only part of the page without a full reload. This can produce a smoother result for sensor dashboards, though no full JavaScript example is provided in the sources.

Can you run other code in loop() alongside the web server?

Yes. The arduino-esp32 core runs on top of ESP-IDF, which uses FreeRTOS. AsyncTCP runs the server's event callbacks in its own FreeRTOS task, while loop() runs in a separate task. Both take turns on the processor, so you can safely read sensors, update a display, or control GPIOs in loop() without interfering with the web server.

One critical rule: do not call delay() or yield() inside an async server callback. Because these tasks are non-preemptive — only one runs at a time — blocking inside a callback prevents the AsyncTCP event task from processing other events. Pending connections stall and clients time out. If a request handler needs significant processing time, the recommended pattern from the sources is to set a shared flag variable inside the callback and do the actual work in loop() on the next iteration.

What are the most common mistakes?

The hardened WebServer library also enforces a default maximum URI length of 2048 characters (WEBSERVER_MAX_URI_LEN) and a per-line read timeout of 5000 ms (WEBSERVER_MAX_LINE_WAIT). Normal browser traffic stays well under both limits, but scripts that send very long URLs or stall mid-request will now receive a clean 414 URI Too Long or 408 Request Timeout response instead of consuming heap memory indefinitely. All these limits are plain macros with #ifndef guards, so they can be overridden at build time without editing the library.

This guide summarises the public sources listed above in our own words. Check the original documentation before relying on exact figures.
